12HP Walking Tractor, Single-axle Tractor, Walk-behind Tractor
Go back to Catalog: Walking Tractor
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
We can supply spare parts within 15 business days or sooner. Please offer the parts number and when the machine you bought and what the brand of engine, transmission etc. If you are not sure, please contact us directly. Quality, ReliabilityCustom Farm machienry Get a Discount Price,Order now or contact if you have any questions
12HP Walking Tractor Series
12HP Walking Tractor such as a trailer, cultivator or harrow, a plough, or various seeders and harvesters
12HP Walking Tractor such as a trailer, cultivator or harrow, a plough, or various seeders and harvesters
|
Engine |
Pattern |
Vertical, One Cylinder, Four Stroke, Diesel powered, Water-cooled |
| Model | 1105 | |
| Displacement(L) | 1.194 | |
|
Oil Consumption (g/ km. h) |
< 320 | |
| Engine Oil Consumption (g/ km. h) | < 2.72 | |
| Rated Power(kw) | 13.23 | |
| Rated Speed(rpm) | 2000 | |
|
Machine Parameters |
Type | Pull and Drive |
| Overall Size(mm) | 2680*960*1250(without seat) | |
| Wheel Tread(mm) | 800 | |
| Minimum Ground Clearance(mm) | 185 | |
| Minimum Turning Radius(m) | 0.9 | |
| Structural Weight(kg) | 360 (with connecting frame), 480(with rotary tiller) | |
| Tyre | 6.00-12 | |
| Theoretical Speed (km/h) |
Forward: 1.4, 2.5, 4.1, 5.3, 9.4, 15.3 Reverse: 1.0, 3.8 |
|
| Rated Traction(N) | 2400 | |
| Gearbox | (3+1 ) × 2 | |
| Oil Type | 0# in summer, -10 or 20 in winter | |
| Cooling Type | Evaporation | |
| Rear-Wheel Diameter (mm) | 340 |
