15HP Walking Tractor, 15HP Hand Tractor, Heavy Duty 2 Wheel Tractor
Go back to Catalog: Walking Tractor
Package: Pallet Packing or as customer requier
Minimum Order: 1 SET
Delivery Time: 15 Days - 30Days
Export Markets: North America, South America, Eastern Europe,
Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
By wheel: 2WD/4WD
Color : Green, Red, Blue, on request
Payment Terms: T/T, L/C At Sight
We can supply spare parts within 15 business days or sooner. Please offer the parts number and when the machine you bought and what the brand of engine, transmission etc. If you are not sure, please contact us directly. Quality, ReliabilityCustom Farm machienry Get a Discount Price,Order now or contact if you have any questions
15HP Walking Tractor Series
Heavy Duty Hand Tractors, Walk Behind Tractor 15 HP Walking Tractor with Loncin Engine
Overall Dimension(mm) 2170× 930× 1150
Ground Clearance(mm) 210
Engine ZH1100
Power 15 HP
Wheelbase(mm) 680~1200
Weight(kg) 370
Semiaxis cm 520-600
Weight in use(with oil, water, tools) (kg) 430
Tyre Model 6.00~16
Tyre Pressure Field Work 100~120(1.0~1.2kgf/c)
Transportation Work 180~200(1.8~2.0kgf/c)
Power Connection 1040
Three B1900 cone Belts.
Heavy Duty Hand Tractors, Walk Behind Tractor 15 HP Walking Tractor with Loncin Engine
Overall Dimension(mm) 2170× 930× 1150
Ground Clearance(mm) 210
Engine ZH1100
Power 15 HP
Wheelbase(mm) 680~1200
Weight(kg) 370
Semiaxis cm 520-600
Weight in use(with oil, water, tools) (kg) 430
Tyre Model 6.00~16
Tyre Pressure Field Work 100~120(1.0~1.2kgf/c)
Transportation Work 180~200(1.8~2.0kgf/c)
Power Connection 1040
Three B1900 cone Belts.
|
Model |
Unit | ty-151E | |
| Structure weight | Without rotary tiller | kg | 238 |
| With rotary tiller | 291 | ||
| Working weight (with rotary tiller) | kg | 331 | |
| Overall dimensions (L*W*H) | mm | 2170x845 x 1150 | |
| Number of blades | PCS | 14 | |
| Rototilling width | mm | 700 | |
| Type of tractor |
|
Single axle, dual-purpose for both traction & drive | |
| Travelling speed | Forward | Km/h | 1.98, 3.08, 4.98, 8.04, 12.49, 20.2 |
| Reverse | 1.53, 6.18 | ||
| Type size |
|
6.00-12 | |
| Wheel track | mm | 680~740(adjustable) | |
| Min. ground clearance | mm | 210 | |
| Min. turning radius | m | 0.71 (without rotary tiller) | |
| Model of engine |
|
190NE | |
| Type of engine |
|
Horizontal 4-stroke | |
| Bore x stroke | mm | 90× 90 | |
| Total displacement | L | 0.573 | |
| Compression ratio |
|
21: 01 | |
| Turing speed of crankshaft | rpm | 2300 | |
| 1-hour rated output | KW/hp | 7.7/10.5 | |
| 12-hour rated output | KW/hp | 7.0/9.5 | |
| Specific fuel consumption | g/kw. h | ≤ 273.4 | |
| Specific lube oil consumption | g/kw. h | ≤ 2.72 | |
| Cooling mode |
|
Condenser (Radiator) | |
| Main farm implements (optional) |
Anti-skid steel wheel Model 100-640 Single-furrow plough Model 1LS-125 Turnover plough Rotary tiller Model MX80D-1 Sprinkler Model 50BPZ-45 Swather/reaper Model 4GL-100 Trailer 7C-0.8 (Standard) |
||
